2dBi 512MHz Ultra Low Frequency Antenna

Dongguan Chaowei Electronics Co., Ltd
Contact Now

2dBi 512MHz Ultra Low Frequency Antenna

Brand Name : chaowei

Model Number : CW-L007

Certification : BSCI CE Fcc RoHS Trade Mark Patent ISO9001:2008

Place of Origin : Guangdong China

MOQ : 10-100 pcs

Price : negotiable

Payment Terms : T/T and other payments can also be negotiated.

Supply Ability : 5000 Pieces per Month

Delivery Time : 1-7 work days

Packaging Details : Single package size: 35X5X5 cm Single gross weight: 0.300 kg

Product Name : 2dBi 20-512MHz TNC Wireless Rubber Materials Bendable Antenna

Frequency range : 20MHz-512MHz

Gain (dBi) : 2

VSWR : ≤2.5

Polarization : Linear

Impedance : 50 Ohm

Connector Type : TNC Male

Color : Black

Contact Now

2dBi 512MHz Ultra Low Frequency Antenna

Factory Price 2dBi 20-512MHz TNC Wireless Rubber Materials Bendable Antenna

Specifications

A.Electrical Characteristics
Working Frequency 512MHz
S.W.R <2.0
Typical Antenna Gain 2dBi
Polarization Vertical
Impedence 50 Ohm
B.Material
Marerial of Plastic TPEE
Coaxial Cable RG178/U
Connector Type SMA male
C.Environmental
Operation Temperature —20℃——70℃
Storage Temperture —20℃——70℃

FAQ

1 Q: What is you brand ?A ODMOEM

2 Q: Can I choose a different connector?

A: We can customize dfferent connector according to your requirements 3 Q: Can you proyide customization?

A Of course.Persnalized designs of the preducts accoraing to custome's requiremens are welcomed.

4 Q:Can you send a sample for us to develop?

A Yes,normally we can provide 1 cr 2samples of the small antenna for free,to be fair buyers need to bear the freight.

5 Q: How much the shipping cost will be for sample ?A It depends on the specifc weight and packing size of the goods

6 Q How can Iget the cable price list ?

A Please contact us with detal inquiry information,so we can cffer the latest price for you

7 Q: What's your MOQ?

A In generally,we will sk at least 100pcs for the Antenna which we can make further negtitio.

8 Q:What's the dellvery time?

A Generally, we can deliver the cables in 3-5working days cnce the paymentis confimed. Mas5 production can be negotiated 9Q:How do you solve after sale service?

A Afer the receip of goods, iyou are not satisfied or any other problems,please contact us to communicate as soon as possible,we will give you a quicky and reasonable solution.Thanks a lot!

2dBi 512MHz Ultra Low Frequency Antenna2dBi 512MHz Ultra Low Frequency Antenna2dBi 512MHz Ultra Low Frequency Antenna


Product Tags:

512MHz Ultra Low Frequency Antenna



2dBi Ultra Low Frequency Antenna



2dBi tnc antenna


Quality 2dBi 512MHz Ultra Low Frequency Antenna for sale

2dBi 512MHz Ultra Low Frequency Antenna Images
